OEM/ ODM Acceptable, Manufacture of Kiosks.
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | HE |
| Certification: | CE/CCC/FCC/ROHS/ISO9001 |
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Packing (Foam and Wooden Crate) |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 pieces per month |
| Logo: | Customized | Power:: | 80-3000W |
|---|---|---|---|
| Packaging: | Customized | Graphic: | Customized |
| Deviation Of Erro: | ±<1.0% | Warranty: | 1 Year |
| Memory:: | 2GB DDR, 16GB EMMC | Thermal Printer:: | Paper Width 80mm, 80mm, With Auto Cutter Printing Speed: |
| Resolution: | 1080*1920 | Payment (Optional）: | Contactless Card Reader TPS900: All-in-One EFT POS Inte |
| Face Recognition (Optional): | Single-lens Camera Dual-lens Camera 3D Depth Sensing Cameral | Peripheral Ports: | 2 USB Host, 1 RJ45, 1 Micro USB |
| High Light: | Touch Screen Digital Self Service Kiosk,Restaurant Digital Self Service Kiosk |
||
checkout payment ordering restaurant order prices touch screen stands digital kiosk
Selling Point
Capacitive touch screen, Original IPS screen, Built- in speaker, Standing or wall hanging, receipt printer, key lock cabinet, credit card terminal stand, NFC reader.
Product Advantages
1. The screen is designed with capacitive touch.
2. The system support WIN and Android.
3. The machine equipped with A grade IPS panel
4. It can provide QR Code Scanner.
5. It' s easy to change the paper with the swich lock.
6. It' s your choise to use NFC/POS.
7. It can be installed on wall or designed on floor standing according to the place where it will be.
| 32 Inch Self-Service Ordering Payment Kiosk | |||
| Model | Parameter | ||
| Panel | LCD | 32" | |
| Light | LED back light | ||
| Resolving | 1920×1080 (pixels) | ||
| Brightness | 360cd/m²(typ.) | ||
| Contrast | 2500:1(typ.) | ||
| Reaction | 5ms(typ.) | ||
| Pixel | 0.3114 mm×0.3114mm | ||
| Frame | 60Hz | ||
| Visual | 178°(H)/178° (V) | ||
| Service | 50,000 hrs(min.) | ||
| Visible | 698.4mm×392.85mm | ||
| Color | 16.7M(8bit) | ||
| Android configuration (standard) | CPU | Framework | RK3288 Cotex-A17 |
| Operating frequency | 1.8GHz | ||
| GPU | Four core | ||
| Internal | Standard 2g (4G optional) | ||
| Internal | Standard 8g (16g / 32g / 64g optional) | ||
| System | Android 5.1 or later | ||
| Motherboard | MIC-IN*1,RJ45*1,HDMI*1,SD*1,SIM*1,USB*2 | ||
| PC configuration (optional) | Processor | Intel J1900 quad core / I3 / i5 / i7 | |
| Hard disk | 64g SSD / 128G SSD / 1t Mechanical hard disk | ||
| Memory | 4GB/8GB | ||
| WIFI | 802.11 b/g/n | ||
| Network card type | 1 Gigabit network card (rtl8111e) | ||
| Motherboard interface | HDMI*1,VGA*1,RJ45*1,USB*4,LINE-OUT*1,MIC-IN*1 | ||
| Peripheral | Printer | 80mm panel thermal printer | |
| A Scanner | QR code automatic scanning mp150 | ||
| NFC card swiping | Optional | ||
| Camera (optional) | Wechat 3D structured light camera / Monocular camera / Binocular camera | ||
| POS (optional) | External POS machine | ||
| Power Supply | Voltage | 100V~240V,50-60Hz | |
| Maximum power | 80W | ||
| Standby power | ≤1W | ||
| Environment | Working temperature | 0℃～50℃ | |
| Storage temperature | -20℃～60℃ | ||
| Storage humidity | 5%～90%RH | ||
| Working humidity | 10%～90%RH | ||
| Function | Internal horn | 5W × two | |
| Power supply (AC) input | × one | ||
| Power switch | × one | ||
Professional Customized Services
* We solemnly promise that the products are 100% official genuine quality assurance!
* Multiple inspection procedures, rigorous packaging and full escort!
* Strict cost control and large- scale production make the price of products more competitive and pursue high cost perfmance!
* Humanized professional design, while providing standard solution, can also be customized according to the individual needs of customers.
Professional customization, customized appearance, color and function modules can be added according to customers personalized needs.
