OEM/ODM Acceptable, Manufacturer of Kiosks.
 |
| Place of Origin: | Guangdong, China |
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | With standard packaging or according to customer's request |
| Delivery Time: | 15~20 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 per month |
| Standard: | Compliant With Most Banking Standard Specifications, Including CEN/XFS, NDC, DDC, ISO8583, Etc. | OS: | Microsoft Windows 10 |
|---|---|---|---|
| CPU: | Support Intel Core I3/i5/i7 CPU | RAM: | Support Max. 16GB Memory |
| HDD: | Support Max. 1 TB Hard Disk | Communication: | RJ45, WIFI, X.25, Etc. |
| Power: | AC 220V~240V,50~60 Hz, Surge Protection, UPS(opt.) | Cash Bag: | 1 Unit |
| Capacity: | Capacity ≧15000 Banknotes, Up To 200 Banknotes Per Transaction, Speed ≧700 PPM, Support Continuous Banknote Feeding. | OCR: | Support Banknote Serial Number Recognition (opt.) |
| Highlight: | Automatic Banknote Deposit Machine,Smart Banknote Deposit Machine,Cash Deposit Machine |
||
Smart Automatic Banknote Deposit Machine Cash Deposit Machine (CDM) D04L
Advantages:
| Dimensions | Width | 395mm |
| Height | 1340mm | |
| Thickness | 615mm | |
| Net Weight | 230kg | |
| Backing plate and carton packaging weight | 260kg | |
| Backing plate and wood packaging weight | 275kg |
Summary:
| Standard | Compliant with most banking standard specificatons, including CEN/XFS,NDC,DDC,ISO8583,etc. | |
| Security | Safe | UL 291 Level 1 Compliant |
| Lock | Mechanical combination lock | |
| Cameras | Binocular recognition camera(opt.), Ordinary facial camera(opt.), Ordinary exit slot camera(opt.), Ordinary room camera(opt.), Ordinary extra camera(opt.) |
|
| Sensors |
Hunan sensor Shock sensor(opt.), Infrared sensor(opt.),
Smoke sensor(opt.), Light sensor(opt.)
|
|
| Others | Explosion-proof glass, PIN Pad shield, DVR(opt.) | |
| Controlling Unit | OS | Microsoft Windows 10 |
| CPU | Support Intel Core i3/i5/i7 CPU | |
| RAM | Support Max.16GB memory | |
| HDD | Support Max.1TB hard disk | |
| Communication | RJ45, WIFI, X.25, etc. | |
| Power | AC 220V~240V,50~60 Hz,Surge protection,UPS(opt) | |
| Cash Processing Unit | Cash bag | 1 Unit |
| Capacity | Capacity ≧15000 banknotes, up to 200 banknotes per transaction, Speed ≧700 PPM, Support continuous banknote feeding. |
|
| OCR | Support banknote serial number recognition(opt.) | |
| Customer Interface | Display | 12.1” TFT color LCD touch screen; Privacy mirror; Sunlight readable |
| Keypad | PCI compliant, 4*4 metal encryption PIN pad, 2*4 function keys, Dust proof/water proof/vandal resistant, Support customizable panels, Support braille key |
|
| Card Reader |
EMV certified, Motorized card reader; DIP card reader (opt.),Contact
less smart card reader/writer (opt.), Card retract (opt.), Card return on power failure
(opt.), Anti-skimming design (opt.)
|
|
| Printer |
Graphic thermal receipt printer, E-journal printer, Journal printer (opt.)
|
|
| Light |
Top light, Device guide light, Status indicator light, LED electronic screen
light(opt.), Logo light(opt.)
|
|
| Others |
Bar code reader (opt.), Customer awareness mirror, Speaker, Audio jack
|
|
| Additional Module |
Power amplifier board, USB extension board, Fan, Heater(opt.)
|
|
| Environment | Work Environment |
Temperature:-10℃~+65℃(+14℉~+149℉)(Indoor),-35℃~+75℃(-31℉~+167
℉)(Outdoor with heater)
Humidity: 20%~85%(No condensation)
|
| Storage Environment |
Temperature: -20℃~+85℃(-4℉~+185℉)
Humidity: 5%~90%(No condensation)
|
