Cash Recycling Machine (CRM) C03T-Z Smart Automatic Banknote Recycling Machine
Product Advantages
Reliability
C03T-Z provides users with maximum online uptime, minimal maintenance requirements, and the lowest repair costs.
Security
C03T-Z provides superior security for users. It features a UL/CEN-compliant safe, an EMV-compliant card reader and a PCH-compliant EPP, along with a facial recognition camera and an exit slot camera.
Flexibility
C03T-Z features a modular design. It supports a variety of optional modules, allowing users to customize according to their individual needs.
User-friendly
C03T-Z features a highly humanized design, including chamfered corners, a rear status indicator light and more. It supports the majority of SWITCH's online transactions.
Dimensions
| Width |
500mm |
| Thickness |
1015mm |
| Height |
1590mm |
| Net Weight |
450kg |
| Backing plate and carton packaging weight |
460kg |
| Backing plate and wood packaging weight |
470kg |
Detailed Product Configuration
| Software |
Compliant with CEN/XFS standard, support different protocols like: NDC, DDC, ISO8583, etc |
| Security |
Safe: UL 291/CEN 1
Lock: Key Lock, Mechanical Combination Lock, Digital Lock
Camera: Binocular Camera (opt), Facial Camera, Cash Slot Camera
Sensor: Body Sensor, Door Sensor, Infrared Sensor (opt), Smoke Sensor (opt), Light Sensor (opt)
Others: Explosion proof Glass, PIN Pad Shield, DVR (opt), Privacy Mirror
|
| Controlling Unit |
OS: Win10/Win 11
CPU: Support Intel Core i5/i7
RAM: Support 8/16/32 GB Memory
HDD: Max 1 TB Hard Disk
Communication: RJ45, WIFI, X 25, etc
Power: AC 220v~240v, 50~60 Hz, Surge Protection, UPS (opt)
|
| Additional Module |
SIU Control Board, Fan, Heater (opt) |
| Cash Recycling Unit |
Cassette: 4 Recycling Cassettes, 1 Reject/Retract Cassette
Capacity: 4 recycling cassettes support to extend to Max 8 recyclable subunits, the recycling cassette supports Max 3400 banknotes, the reject unit and the retract unit support Max 3400 banknotes Up to 300 banknotes per transaction, 13 banknotes/second
OCR: Support Banknote Serial Number Recognition
|
| Environment |
Work Environment: Temperature: 10°C~+65°C (+14°F~149°F) (indoor), 35°C~+75°C (31°F~+167°F) (outdoor with heater), Humidity: 20%~85% (no condensation)
Storage Environment: Temperature: 20°C~+85°C (4°F~+185°F), Humidity: 5%~90% (no condensation)
|
| Customer Interface |
Display: Front display 15" TFT Color LCD Touch Screen/Rear display 10.4" HD Touch Screen, Sunlight Readable
EPP: PCI compliant, 4x4 metal EPP, 2x4 function keys, dust/water/vandal resistant, support customizable layout and braille key
Card Reader: EMV Motorized Card Reader, DIP Card Reader (opt.), Contactless Card Reader (opt.) Card Security: Card Retract (opt.), Card return on power failure (opt.), and Anti-skimming
Receipt Printer: Graphic Thermal Receipt Printer, E-journal
Light: Device Guidance Light, Status Indicator Light, LED Electronic Screen Light (opt.), Logo Light (opt.)
Others: Bar Code Reader, Fingerprint Reader (opt.), Speaker, Audio Jack
|
Frequently Asked Questions
Q: What's the condition of your product?
A: Generally we can provide 4 conditions: new original, new generic, original used and original ref.
Q: Is your products have a warranty?
A: Yes. Every product has a warranty, normally it is 3 months.
Q: Do you have your own factory?
A: Of course yes. We have our own factory, we can build the molds and produce parts by ourselves.
Q: What's the lead time of your product?
A: Normally it is 3-7 days after payment. The lead time is related to the quantity you ordered.
