23.6 Inch Touch Screen Self Service Cashless Kiosk Machine K33L
1. Product Advantages
Reliability: K33L provides users with maximum online uptime,minimal maintenance requirements, and the lowest repair costs.
Security: K33L delivers superior security for users, featuring a facial recognition camera along with EMV and PCI compliance.
Flexibility: K33L features a modular design.lt supports a variety ofoptional modules, allowing users to customize according to their individual needs.
User-friendly: K33L features a highly humanized design, includingchamfered corners, a rear status indicator light and soon. And it supports the majority of SWITCH's onlinetransactions.
2. Dimension
| Dimension |
Freestanding |
Desktop |
Wall-mounted |
| Width |
500mm |
500mm |
299mm |
| Thickness |
415mm |
350mm |
216mm |
| Height |
1720mm |
836mm |
832mm |
| Net Weight |
50kg |
50kg |
50kg |
| Backing plate and carton packaging weight |
60kg |
60kg |
60kg |
| Backing plate andwood packagingweight |
65kg |
65kg |
65kg |
3. Detaild Product Configuration
| Software |
Flexible with different protocos like: API, ISO8583,Java,etc. |
| Security |
Lock |
Key Lock |
| Camera |
Facial Camera (opt.) |
| Sensor |
Door Sensor, Infrared Sensor (opt.), Smoke Sens or (opt.), Light Sensor (opt.) |
| Others |
Explosion proof Glass, DVR (opt ) |
| Controlling Unit |
OS |
Microsoft Windows 10/Windows 11 |
| CPU |
Support Intel Core i5/i7 |
| RAM |
Support 8/16/32 GB Memory |
| HDD |
Max 1 TB Hard Disk |
| Communication |
RJ45, WIFI, X 25, etc |
| Power |
AC 220v~240v, 50~60 Hz, Surge Protection, UPS (opt) |
| Additional Module |
SIU Control Board, Fan, Heater (opt ) |
| Environment |
Work Environment |
Temperature: 10°C~+65°C (+14°F~149°F) (indoor), 35°C~ +75°C (31°F~ +167°F) (outdoor withheater), Humidity: 20%~85% (no condensation) |
| Storage Environment |
Temperature: 20°C~ +85°C (4°F~+185°F), Humidity: 5%~90% (no condensation) |
| Customer Interface |
Display |
23.6" TFT Color LCD Touch Screen, Privacy Filter(opt.), Sunlight Readable |
| Card Reader |
Contactless Card Reader(opt.); Card Security: Anti-skimming |
| Receipt Printer |
Graphic Thermal Receipt Printer,E-journal |
| Light |
Device Guidance Light, Status Indicator Light, LED Electronic Screen Light (opt.), Logo Light (opt.) |
| Others |
Bar Code Reader, Fingerprint Reader (opt.), Speaker, Audio Jack
|
4. Company Introduction
HERONG Intelligent EquipmentTechnology Co., Ltd. is a professionalmanufacturer integrating R&D, production,assembly, sales and service. We areproficient in various types of plastic moldsand CNC hardware processing. We haveadvanced molding equipment, and haveset up our own CNC machining center,which can perfectly undertake ATM parts,auto parts, household appliances, dailynecessities, electronic products, medicalequipment and other projects.
We have different sectors of businessincluding ATM Spare Parts, BankingMachines, Software Solutions, Servers,E-business,etc..
By continuously developing new products,improving product quality and providinggood services, we have maintained verygood cooperative relationships with ourcustomers, who are located in more than130 countries all around the world.
5. Shipment
RFQ:
Q:what’s the condition of your product?
A:Generally we can provide 4 conditions:new original,new generic,original used and original ref.
Q:Is your products have a warranty?
A:Yes.Every product has a warranty,normally it is 3 months.
Q:Do you have your own factory?
A: Of course yes.We have our own factory,we can build the molds and produce parts by ourselves.
Q:What’s the lead time of your product?
A:Normally it is 3-7 days after payment.The lead time is related to the quantity you ordered.
